FUNCTIONALITY AND EFFICIENCY

As it has a closed chamber, the Harrison utilises four methods of heat transference: radiation, convection, conduction and direct heat. These ovens don’t need electricity or gas and can work with any type of charcoal and many types of wood.

The temperature is controlled by an exterior handle that increases or decreases air-flow to the solid-fuel chamber from the lower vent. The immediate impact that has on the embers - and therefore the temperature - is exhilarating to see. As the top vent draws the air through the oven’s closed-chamber the temperature will build.

From a cold-start it takes roughly 30 minutes to get up to cooking temperatures of 250-300 degrees. After another 15 minutes or so, the walls of the chamber become 'charged', which means the Harrison is now using radiant heat, which can be retained for a whole service if required.

The Harrison is quick, easy, and clean to light using additive-free firelighters. The choice of wood or wood chips used will have a subtle but distinctive impact on flavour, and the same is true of the choice of charcoal too.

FUEL SOURCE

Charcoal and wood are organic, natural, non-toxic and more cost-effective than conventional-fuel ovens. The average consumption is 3Kg coal for a full food service (depending on the menu / covers etc). Harrison’s chamber has been designed to retain heat, which means it cooks 35% faster than an open charcoal grill and uses 40% less coal.

Charcoal is best for slow cooking, high temperature cooking and baking. Harrison recommend using 100% sustainable, finest quality, restaurant grade.

Briquettes are blocks of compressed charcoal, which can be used across baking, high and ultra-high temperature cooking, as they tend to last for longer periods of sustained, consistent temperature cooking. They are harder to light than standard charcoal.

Untreated, dry wood works well and can add subtle smoky notes to your cooking. Use for hot smoking, baking breads and pizzas. Try different kinds of wood, or wood soaked in aromatic liquids for creative flavour variations.

Wood chips are great for hot smoking and are available in several varieties, such as oak and beech. To add an infused-flavour, soak chips in a liquid flavour of your choice, then place in the oven to add smoky notes of your chosen wood or liquid to your cooking.

Wood dust smoulders and burns cool producing lots of smoke with very little heat. Use in a cold smoke generator to turn your Harrison Oven into the perfect cold smoker.

Harrison Ovens-4280-1.jpg

Inside the Harrison

The metal shelves inside the oven are as strong as the rest of the Harrison and hold their own weight when pulled out. They can be positioned at various heights to maximise the Harrison’s range of temperature capabilities and be cooked on directly for the most searing temperatures. Its exterior roof shares some of the heat of the inside and can be used for resting, warming or sauces.

EXTRACTION

When using your Harrison oven inside, it should be positioned under an extractor hood. Due to the nature of burning solid fuels, the minimum extraction rate will always be 750m3/hour or higher, therefore a standard, domestic extractor hood may not be sufficient. Before installing your oven, advice should be sought from an extraction expert as to your exact needs.

The extractor unit must vent outside and not recycle the air back into the room. The exact rate of extraction required will vary due to the dimension of the room, natural ventilation and airflow and any other equipment being used in the vicinity.

As with any solid-fuel burning device, a carbon-monoxide monitor should always be used in conjunction with an extraction hood.



Cooking Guide

Temp Method Dish
300°C+ Direct, conduction, radiation Tomahawk steak, flat bread, pizza, pastel de nata
250°C+ Direct, conduction, convection, radiation Charred asparagus, whole seabass, roast duck, shakshuka
150–200°C Convection, radiation Sourdough loaf, banana bread, steamed brocolli, grilled figs
100°C Direct, convection, radiation Beef bourginon, roast leg of lamb, ratatouille
80–90°C Convection, radiation Pulled pork, oxtail
10–15°C Cold smoke generator Cheese, fish, bacon, ham, garlic, fruit

Harrison Ovens-4887.jpg

Maintenance

A Harrison Oven is a robust piece of kit that has been handmade, and therefore built to last a lifetime. Each oven comes with a 3 year warranty on parts and labour. As there are 64 components, care does need to be taken to maintain your Harrison and ensure the parts are able to function. You will find care instructions in the user manual.

USER INSTRUCTIONS

Every Harrison oven comes with a full user guide. If you would like to see how to use a Harrison, download the user guide (4.7mb PDF).



Technical choice 2.jpg


Specifications

Manufacturer Harrison Ovens;
Model Harrison ‘S’ / Harrison Classic
Description; Solid fuel, closed chamber oven
Dimensions (W×H×D) 600mm × 600mm × 600mm
Purpose Interior & exterior, solid fuel oven for domestic and commercial use.
Construction Hand made, welded and bolted, high quality stainless steel and mild steel.
Firing Type Charcoal, wood, wood chips.
Exhaust requirements Under locally approved extraction hood, see HSE UK gov guidelines.
MEP ratings Gas N/A, electric N/A, install under approved extraction hood.
Capacity Effective cooking area: 340mm × 380mm × 440mm
Cooking racks (3 max) dimensions: 360mm × 430mm
Accessories Additional drip tray, cooking racks, cabinet, waterproof cover.
Safety Dispose of hot ashes in approved metal container.
Use CO detector indoors.
Follow local Health and safety guidelines
Special requirements Always use extraction indoors.
Allow oven to cool before cleaning.
Reguarly clean ash from tray.
Weight 100kg
Materials 304 grade stainless steel and CR4 DC01 steel.

Download Specifications PDF
